ATC Alignment Gage (TAG) · BT shank
47BT30TAG
47BT30TAG — ATC Alignment Gage (TAG), BT shank (ATC alignment). Spindle Taper 30. Precision-manufactured by PTP CNC Toolings, Belgaum, India. ISO 9001 certified, proof-tested at 2.5× clamping force. Request a quote and CAD files.
About 47BT30TAG
47BT30TAG is a ATC Alignment Gage (TAG) with a BT shank that sets and verifies automatic-tool-changer (ATC) arm alignment to the spindle centreline, conforming to ATC alignment. It is designed to fit machining centres with BT spindle tapers (MAS-BT 7388-2-J / ISO 7388-2). It is precision-manufactured by PTP CNC Toolings Pvt. Ltd. — a precision tool-holder manufacturer in Belgaum, Karnataka, India, established 1985, ISO 9001 certified and IATF aligned, and proof-tested at 2.5× clamping force before dispatch.
Key dimensions for 47BT30TAG: a spindle taper of 30. Full specifications are listed in the table below; request DXF/STEP CAD files for exact geometry.
47BT30TAG belongs to the ATC Alignment Gage (TAG) series. Adjacent sizes and configurations in the same series include 47BT40TAG, 47BT50TAG, 47HSKA50TAG, 47HSKA63TAG — compare their dimensions to select the correct BT model for your spindle and tool diameter.
Specifications
| Ordering Code | 47BT30TAG |
|---|---|
| Product | ATC Alignment Gage (TAG) |
| Shank Type | BT |
| Standard | ATC alignment |
| Spindle Taper | 30 |
Frequently asked questions
What are the specifications of 47BT30TAG?
47BT30TAG is a ATC Alignment Gage (TAG) with a BT shank, conforming to ATC alignment. Key specifications — Spindle Taper: 30.
What is 47BT30TAG?
47BT30TAG is the ordering code for a ATC Alignment Gage (TAG) from PTP CNC Toolings Pvt. Ltd. — a precision tool-holder manufacturer in Belgaum, Karnataka, India, established 1985, ISO 9001 certified and IATF aligned.
What machines is 47BT30TAG compatible with?
47BT30TAG fits machining centres with BT spindle tapers (MAS-BT 7388-2-J / ISO 7388-2). Confirm your spindle taper and drawbar before ordering. PTP can supply matching pull studs and accessories.
How do I order 47BT30TAG?
Request a quote for 47BT30TAG from PTP CNC Toolings by phone (+91-9538456478), email (ptpcnc@ptpcnctoolings.com), or WhatsApp. CAD files (DXF/STEP) are available on request.
